ERALUX РVADOR EVOLVE – VDE
The VADOR EVOLVE Series is an energy-efficient and economical LED linear fixture designed for harsh environment and industrial suited applications where dust and water resistance are necessary. This fixture is configured with adjustable power and CCT switches that can cover most of your project needs. Integrated lens and module plate that makes the installation process simply a breeze.
ADDITIONAL INFORMATION
OPERATIONS & ELECTRICAL
Input voltage : 120~347V
Power factor : 0.9
Total harmonic distortion (THD) : <20%
Dimming : 0-10V
Lumens per Watt : 130 LPW at 80CRI
Beam Angle: 120Àö

80 CRI

3500K

4000K

5000K

CCT Switchable

Power Switchable
Easy Assembly and Maintenance
Integrated lens and module plate make it easy to open fixtures for assembly.
